HPEDM® system 3R wire EDM ruler 3R-200.4J-1

HPEDM system 3R Reference element WEDM   HE-R06774.395

Compatible with 3R-200.4J-1

Reference  element  WEDM

Reference element WEDM
Reference elements for machines with zero-line table. The
length (L), hole spacing (C) and hole edge spacing (B) of the
hardened reference elements are matched to the machine in
question.

Length=495mm  Pitch C=50mm    40 mm from the table edge
Note: When ordering, state machine mark and type.
• Supplied with end stops

for wire EDM machine table
