HPEDM CNC 4 axis multi position vise

Description

  HPEDM CNC multi position vise   HE-R06913.b

calmping force:

Wide: 50mm               1000kgf

Wide: 72mm                2000kgf

Wide: 100mm              3000kgf

specifications:  manual,

Parallelism: 0.003mm/100mm.

Squareness:  0.005mm/100mm

Material:  SK2

Harden:  56°-58°.

Application: Mount On 4 axis CNC  machine center,   It can be rotated when processing workpieces.

Advantage: 1. The vise can be  adjustable and is  different from traditional vise,  It enlarges clamping dimension

2. It can clamp workpiece in square, round and irregular shapes.

3. It can clamp more workpieces at a time and reduce the time of changing workpieces, Which can improve your efficiency furthest

4. The usage rate of  vice is very high, which reduce your cost, Also, It can not moved when clamping workpiece,  operation are very easy, Even for new operators.
