HPEDM® System 3R Pneumatic chuck,MacroTwin 3R-602.12-1

HPEDM system 3R Pneumatic chuck, MacroTwin  HE-R06972

compatible with 3R manual chuck 3R-602.12-1

Specifications:

Specifications:

Pneumatic chuck for Macro or MacroTwin. Horizontal mounting

on the machine table. Supplied with two drawbars 3R-605.10

and protective covers.

Note: On automatic changing with WorkPal – MacroTwin holders

only.

• Fixed index positions 4×90°
• Air-blast cleaning of the Z-references
• Clamping force 2×6700 N
• Weight 1.5 kg

Repeatability: 0.002mm-0.005mm

Mount:  With bolts or clamps.

Repeatability: 0.002mm-0.005mm
