Description
HPEDM 3R EDM tool pallet 54x54mm HE-R06654
Compatible with system 3R-651.7E-P
Specifications:
Hardened and precision-cast, with clearance holes for four
fixing screws.
Note: Must be mounted on the workpiece/fixture before it is
locked in a chuck.
• Adapted for automatic changing
• Parallel-ground top and bottom faces
• Fixed index positions 4×90°
• Rust-resistant
Application: on CNC EDM machine for EDM die sinking.
mount electrodes and workpieces on 3R chuck system
On CNC sinker EDM machine center processing EDM electrode for mould industry
Repeatability: 0.002mm-0.005mm
Mount: With bolts or clamps.
used on system 3R perfectly
